Sensor
3-axis Accelerometer3-axis MagnetometerThermometer
3-axis Accelerometer3-axis MagnetometerThermometer
3-axis Accelerometer3-axis MagnetometerThermometer
Communication
Bluetooth
Bluetooth
RS485 Wire/WiFi 2.4 GHz
Accelerometer -Frequency Range
DC to 6 kHz
DC to 6 kHz
DC to 6 kHz
Accelerometer -Sampling Rate
26 kHz
26 kHz
26 kHz
Accelerometer -Dynamic Range
±16 g
±16 g
±16 g
Magnetometer -Magnetic Flux Density Sensing
±160 mT
±160 mT
±160 mT
Thermometer -Sensitivity
± 0.5°
± 0.5°
± 0.5°
IP Rating
IP67
IP67
IP67
Mounting
Magnetic & Adhesive Mounting
Adhesive & Stud Mounting
Adhesive & Stud Mounting
Storage Temperature
-40 °C to +80 °C
-40 °C to +80 °C
-40 °C to +80 °C
Operating Range
-40 °C to +80 °C
-40 °C to +80 °C
-40 °C to +105 °C
Power
Battery (3.7V, 240 mAh Li-Po)
Battery (1500 Mah LiFePO4)
Wired (5 - 36V)
Battery Life
Up to 6 Months
Up to 2 Years
-
Charge
5V USB & Solar Cell Input
5V USB & Solar Cell Input
-
Communication
BluetoothWiFi
BluetoothWiFiEthernetLoRa
Power
12 - 24V DC
12 - 24V DC
External Input
Trigger & Tachometer
Trigger & Tachometer
Input Voltage High Logic Level
5-24V DC
5-24V DC
Machine Health Condition Monitoring
User-friendly interface lets you monitor state changes of your machines’ health and don’t miss any critical notifications.
About LAKEschedule meeting
| Infinity | Infinity Pro | Wired Pro | |
|---|---|---|---|
| Sensor | 3-axis Accelerometer 3-axis Magnetometer Thermometer |
3-axis Accelerometer 3-axis Magnetometer Thermometer |
3-axis Accelerometer 3-axis Magnetometer Thermometer |
| Communication | Bluetooth | Bluetooth | RS485 Wire/WiFi 2.4 GHz |
| Accelerometer -Frequency Range | DC to 6 kHz | DC to 6 kHz | DC to 6 kHz |
| Accelerometer -Sampling Rate | 26 kHz | 26 kHz | 26 kHz |
| Accelerometer -Dynamic Range | ±16 g | ±16 g | ±16 g |
| Magnetometer -Magnetic Flux Density Sensing | ±160 mT | ±160 mT | ±160 mT |
| Thermometer -Sensitivity | ± 0.5° | ± 0.5° | ± 0.5° |
| IP Rating | IP67 | IP67 | IP67 |
| Operating Range | -40 °C to +80 °C | -40 °C to +80 °C | -40 °C to +105 °C |
| Mounting | Magnetic & Adhesive Mounting | Adhesive & Stud Mounting | Adhesive & Stud Mounting |
| Power | Battery (3.7V, 240 mAh Li-Po) | Battery (1500 Mah LiFePO4) | Wired (5 – 36V) |
| Battery Life | Up to 6 Months | Up to 2 Months | – |
| Charge | 5V USB & Solar Cell Input | 5V USB & Solar Cell Input | – |
 |
 |
 |
|
| Infinity | Infinity Pro | Wired Pro | |
|---|---|---|---|
| Sensor | 3-axis Accelerometer 3-axis Magnetometer Thermometer |
3-axis Accelerometer 3-axis Magnetometer Thermometer |
3-axis Accelerometer 3-axis Magnetometer Thermometer |
| Communication | Bluetooth | Bluetooth | RS485 Wire/WiFi 2.4 GHz |
| Accelerometer -Frequency Range | DC to 6 kHz | DC to 6 kHz | DC to 6 kHz |
| Accelerometer -Sampling Rate | 26 kHz | 26 kHz | 26 kHz |
| Accelerometer -Dynamic Range | ±16 g | ±16 g | ±16 g |
| Magnetometer -Magnetic Flux Density Sensing | ±160 mT | ±160 mT | ±160 mT |
| Thermometer -Sensitivity | ± 0.5° | ± 0.5° | ± 0.5° |
| IP Rating | IP67 | IP67 | IP67 |
| Operating Range | -40 °C to +80 °C | -40 °C to +80 °C | -40 °C to +105 °C |
| Mounting | Magnetic & Adhesive Mounting | Adhesive & Stud Mounting | Adhesive & Stud Mounting |
| Power | Battery (3.7V, 240 mAh Li-Po) | Battery (1500 Mah LiFePO4) | Wired (5 – 36V) |
| Battery Life | Up to 6 Months | Up to 2 Months | – |
| Charge | 5V USB & Solar Cell Input | 5V USB & Solar Cell Input | – |
